The right KNX control panel for your project

KNX is a globally established, open standard for intelligent home and building automation. The system enables cross-manufacturer networking and control of lighting, shading, heating, ventilation and air conditioning, energy management, security technology and many other building functions.

Core automation functions within a KNX installation can operate locally and independently of external cloud services. At the same time, a large number of manufacturers offer certified KNX products. This means users are not permanently tied to a single manufacturer when selecting products or subsequently expanding their installation. Its openness, interoperability and long-term availability make KNX one of the leading international standards for residential and commercial building automation.

The most suitable PEAKnx touch panel depends, among other things, on the required display size and performance, the installation conditions and the functions to be used via the panel.

• Controlmicro: compact 8-inch solution for smaller control areas and flexible installation situations
• Control 12: versatile 11.6-inch panel for smart homes as well as office and commercial projects
• Control 16: 15.6-inch panel with plenty of screen space for a clear visualisation of more extensive KNX projects
• Controlpro: powerful 18.5-inch panel available in three performance variants for particularly demanding applications and projects

Our panel quiz helps you find the model that best suits your individual requirements.

The four PEAKnx touch panels differ primarily in display size, performance, mounting and design options, making them suitable for different requirements.

Controlmicro

• Compact 8-inch display
• Portrait or landscape installation
• Particularly flexible where space is limited

Control 12

• 11.6-inch touch display
• Versatile solution for residential and commercial projects
• Three mounting options: surface-mounted, flush-mounted or flush-with-the-wall

Control 16

• Large 15.6-inch Full HD display
• Optimiertes Verhältnis von Display und Rand
• Optimised screen-to-housing ratio with plenty of space for extensive KNX project visualisations
• Three mounting options: surface-mounted, flush-mounted or flush-with-the-wall

Controlpro

• Large 18.5-inch touch display
• Three performance variants for different project requirements
• Particularly suitable for demanding visualisations and applications

All four models share an open, Windows-based platform and all-in-one functionality with YOUVI Basic, a KNX server and a KNX IP router. Our panel quiz helps determine which panel best suits a particular project.

Yes. A professionally planned KNX system generally operates independently of the internet. Important functions such as lighting control, shading, heating and scenes therefore remain available even if the internet connection is interrupted. Automation takes place locally within the KNX system.

An internet connection is required for functions that access external services, such as certain cloud services, cloud-based voice control or remote access. Depending on the application, these functions can be used via the YOUVI Connect module or the YOUVI App, for example. The building's core control and automation functions remain independent of these services.

PEAKnx touch panels can be used to centrally control and visualise numerous areas of a smart home or smart building.

These include, for example:

• Lighting and shading
• Heating, air conditioning and ventilation
• Energy and consumption data
• Door communication and IP cameras
• Audio systems
• Weather data and sensors
• Other systems connected via KNX or suitable interfaces

With KNX and YOUVI, different building functions can be brought together in a single user interface. Additional modules and bridges can be used to extend the range of functions depending on the project.

Yes. PEAKnx touch panels can be used as all-in-one solutions. With YOUVI Basic, they combine visualisation, a KNX server and a KNX IP router in a single device. The YOUVI App for mobile control is also included.

Depending on the project, this can eliminate the need for separate devices for visualisation, the KNX server and KNX IP interface or router. At the same time, thanks to their open Windows-based platform, the panels can also be used with other visualisation and existing server solutions.

Yes. PEAKnx touch panels are suitable for both new builds and the modernisation of existing KNX installations. In new builds, the panel size, mounting type and installation requirements can be planned to suit the individual project from the outset.

For modernisation projects, we offer suitable replacement kits for numerous older KNX touch panels from different manufacturers. In many cases, existing flush-mounted boxes can continue to be used, avoiding major structural alterations.

KNX has been established as an international building automation standard for decades and is continuously being developed. As numerous manufacturers offer compatible KNX products, installations remain flexible in the long term and can be expanded or modernised as requirements change.

PEAKnx also relies on an open, Windows-based platform. This means users are not permanently tied to a particular visualisation solution and can use other Windows-based and web-based solutions alongside YOUVI. Depending on the project, the touch panels can also be used either as an all-in-one solution or as clients within an existing installation.

Yes. The YOUVI App allows you to control your KNX building automation from a smartphone or tablet. This includes lighting, shading, room temperatures, scenes and other integrated functions.

Control is possible both on the local network and remotely. At the same time, permanently installed PEAKnx touch panels remain available at all times as central control points throughout the building.

PEAKnx touch panels give system integrators a high degree of flexibility when planning and implementing different KNX projects. As all-in-one solutions with visualisation, a KNX server and a KNX IP router, they can perform several functions within a single device. At the same time, the open, Windows-based platform supports YOUVI as well as other Windows-based and web-based visualisation solutions and applications.

Different panel sizes and performance variants, flexible mounting options and replacement solutions for existing KNX installations provide additional flexibility for both new builds and modernisation projects. Development and manufacturing in Germany, together with personal technical support, complete the offering for professional users.
