YOUVI Netatmo Bridge

€39.00
In stock
SKU
PNX31-10005

The Netatmo Bridge for the YOUVI software package Basic enables the integration of Netatmo devices directly into the Smart Home visualisation. Thermostats as well as weather stations and anemometers from Netatmo can be integrated into YOUVI. This way, users can always monitor the weather and temperature in the Smart Home. The integrated Netatmo devices can also be displayed in the YOUVI home control app and are also available outside of your own home network with YOUVI Connect. The Netatmo thermostats can also be controlled automatically via timers or the logic module

> Prices for systemintegrators and traders

30 Days Money Back
Free support
Fast delivery

YOUVI Basic: The intelligent software solution for KNX smart home control

YOUVI Basic combines visualisation, IP router and bus monitor in one package. With the additionally available modules and bridges, the Smart Home functions can be expanded as required.

Integrate weather stations and thermostats into KNX visualisation

The module enables the direct integration of the following Netatmo devices into the YOUVI visualisation:

  • Smart Weather Station (Outdoor Module)
  • Smart Weather Station (Indoor Module)
  • Smart Anemometer
  • Thermostats (Smart Thermostat and Smart Radiator Valve)

No external gateways are necessary for the connection. Both indoor environmental sensors, i.e. CO2, temperature, noise level and humidity, and outdoor sensors (wind direction and speed, humidity, temperature of a weather station) can be displayed. Multiple sensors may be displayed not only individually, but also combined as a weather station widget. A Netatmo thermostat is integrated into YOUVI as a heating widget. Weather and temperature in the Smart Home can now be easily kept in view.

Operate all Netatmo devices via the YOUVI Smart Home app

All connected Netatmo devices are also displayed in the YOUVI Mobile App. If the weather station or thermostats should also be visible outside of your own network, the YOUVI Connect module is required for this. With the module and bridge, the Netatmo devices also appear in the Alexa app without the need for an additional Netatmo Skill.

Use Netatmo devices in logics

All Netatmo devices are also available in the YOUVI logic module and can be used as a trigger, in a condition or – in the case of the thermostat – as an action. For example, a notification can be sent automatically to a PEAKnx touch panel (Controlmini or Controlpro) if the CO2 value rises above a certain threshold and the smart home residents should therefore ventilate urgently.

Hardware and software requirements

The Netatmo Bridge can only be used in conjunction with YOUVI Basic and PEAKnx hardware (Controlmini, Controlpro, USB-Connector or Performance Server).

Installing the Netatmo Bridge

  1. First perform the following steps in YOUVI:
    • If the desired module/bridge has not yet been installed, do it now via YOUVI Dashboard. In case of the YOUVI Netatmo Bridge, click on "Install Netatmo".
    YOUVI Modul Installation Step 1
    • Then open YOUVI Configuration > More > License and select the appropriate license for the module/bridge.
    • Copy the hardware key.
    YOUVI Modul Installation Step 2
  2. Then carry out the following steps in the PEAKnx Shop:
    • Enter the copied code under "Hardware Key". A license key will be generated and stored from it in the following.
    YOUVI Modul Installation Step 3
    • After completing the order process and paying the invoice, you can take the license key from your customer account. In the tab "My license keys" you will find all purchased license keys.
  3. Return to YOUVI:
    • Open YOUVI Configuration > More > License and select the appropriate license for the module/bridge.
    • Enter the license key under the "License" field and select "Activate".
